Dust Collector Machine

Dust Collector Machine

ENDÜSTRİ GM Dust Collection Systems are designed for all kinds of applications and appeal to many sectors. By using it in closed areas, in dense dusty environments, it ensures that the environment is made dust-free and thus, the surface is seen more clearly and thus, the surface quality is increased. At the same time, environmentally friendly machines filter the dust in the environment and throw it cleanly into the atmosphere.

ENDÜSTRİ GM Dust Collection Machines are manufactured in two types. Optionally, vibration motor or jet-pulse versions are available.
Although the filter structure varies according to the granule used, it changes as a cartridge or bag filter.

ENDÜSTRİ GM Dust Collection Machines also consider the emission value
it is a machine with high efficiency. It is a product with increasing value in our country where environmental awareness of Dust Collection Machines started to develop. It is an important machine in terms of work quality and environmental health.


Model 1
EGM SERIES
: DC 3000
Capacity
: 3.000 m³/h
Total Pressure
: 120mmCA
NM (rpm)
: 2.850 rpm
Fan Motor(kW)
: 3,0 kW
Number of Cartridge Filters
: 3
Cartridge Filter Size (Diameter x Length)
: 320x800 mm
Filter Surface
: 24 m2
Number of Pulse Valve
: 2
Height
: 2.140 mm
Width
: 950 mm
Length
: 1.840 mm
Electric Supply
: 380V 60Hz-230 / 380 V 50Hz (for the vessels)
Model 2
EGM SERIES
: DC 9000
Capacity
: 9.000 m³/h
Total Pressure
: 230 mmCA
NM (rpm)
: 2.850 rpm
Fan Motor (kW)
: 7,5 kW
Number of Cartridge Filters
: 9
Cartridge Filter Size (Diameter x Length)
: 320x1000 mm
Filter Surface
: 117 m2
Number of Pulse Valve
: 3
Height
: 2.600 mm
Width
: 1.650 mm
Length
: 1.650 mm
Electricity Supply
: 380V 60Hz-230 / 380 V 50Hz (for the vessels)
Model 3
EGM SERIES
: DC 12000
Capacity
: 12.000 m³/h
Total Pressure
: 250 mmCA
NM (rpm)
: 1.450 rpm
Fan Motor (kW)
: 11 kW
Number of Cartridge Filters
: 12
Cartridge Filter Size (Diameter x Length)
: 320x1000 mm
Filter Surface
: 156 m2
Number of Pulse Valve
: 4
Height
: 2.600 mm
Width
: 1.650 mm
Length
: 2.150 mm
Electricity Supply
: 380V 60Hz-230 / 380 V 50Hz (for the vessels)
Model 4
EGM SERIES
: DC 15000
Capacity
: 15.000 m³/h
Total Pressure
: 270 mmCA
NM (rpm)
: 1.500 rpm
Fan Motor(kW)
: 15 kW
Number of Cartridge Filters
: 12
Cartridge Filter Size (Diameter x Length)
: 320x1000 mm
Filter Surface
: 208 m2
Number of Pulse Valve
: 4
Height
: 2.600 mm
Width
: 2.150 mm
Length
: 2.150 mm
Electricity Supply
: 380V 60Hz-230 / 380 V 50Hz (for the vessels)
Model 5
EGM SERIES
: DC 21000
Capacity
: 21.000 m³/h
Total Pressure
: 300 mmCA
NM (rpm)
: 1.450 rpm
Fan Motor(kW)
: 22 kW
Number of Cartridge Filters
: 16
Cartridge Filter Size (Diameter x Length)
: 320x1000 mm
Filter Surface
: 208 m2
Number of Pulse Valve
: 4
Height
: 2.600 mm
Width
: 2.150 mm
Length
: 2.650 mm
Electric Supply
: 380V 60Hz-230 / 380 V 50Hz (for the vessels)
Model 6
EGM SERIES
: DC 30000
Capacity
: 30.000 m³/h
Total Pressure
: 300 mmCA
NM (rpm)
: 1.650 rpm
Fan Motor(kW)
: 30 kW
Number of Cartridge Filters
: 24
Cartridge Filter Size (Diameter x Length)
: 320x1000 mm
Filter Surface
: 312 m2
Number of Pulse Valve
: 4
Height
: 2.600 mm
Width
: 2.150 mm
Length
: 3.150 mm
Electricity Supply
: 380V 60Hz-230 / 380 V 50Hz (for the vessels)
